Tehnilised andmed
| General | |
| Device Type: | UPS - rack-mountable / external |
| Height (Rack Units): | 5U |
| Colour: | Black, silver (front bezel) |
| Power Device | |
| UPS Technology: | On-line |
| Input Voltage: | AC 230 V |
| Input Voltage Range: | AC 120 - 300 V |
| Frequency Provided: | 50/60 Hz ± 4Hz |
| Frequency Required: | 40 - 70 Hz |
| Input Connectors: | 1 x hardwire 3-wire (1P+ N + E) |
| Output Voltage: | AC 230 V 50/60 Hz |
| Power Capacity: | 6 kW / 6000 VA |
| Output Waveform: | Sinewave |
| Surge Energy Rating: | 600 Joules |
| Efficiency: | 93.5% at 100% Load |
| Battery | |
| Technology: | Lithium Ion lithium ion |
| Voltage Provided: | 48 V |
| Recharge Time: | 5 hours |
| Networking | |
| Remote Management Interface: | RS-232, USB, RJ-11, RJ-45 |
| Expansion / Connectivity | |
| Interfaces: | RS-232 USB Management - RJ-11 Management - RJ-45 |
| Expansion Slots: | 1 (total) / 1 (free) x Intelligent Slot |
| Miscellaneous | |
| Included Accessories: | Stabilisation feet |
| Cables Included: | RJ-45 cable RJ-11 cable RS-232 cable USB cable Battery cable Ground cable |
| Rack Mounting Kit: | Included |
| Features: | Extended runtime, double conversion, LCD display, internal bypass, low battery alarm, overload alarm |
| Compliant Standards: | CB, UKCA, RCM, IRAM, TISI, UN38.3, IEC 62619, IP20, EU RoHS, REACH |
| Environmental Parameters | |
| Min Operating Temperature: | 0 °C |
| Max Operating Temperature: | 40 °C |
| Humidity Range Operating: | 0 - 95% (non-condensing) |
| Sound Emission: | 57.3 dBA |
| Dimensions & Weight | |
| Width: | 43.8 cm |
| Depth: | 68.5 cm |
| Height: | 21.7 cm |
| Weight: | 69.2 kg |
| Dimensions & Weight (Shipping) | |
| Shipping Width: | 60 cm |
| Shipping Depth: | 80 cm |
| Shipping Height: | 65.2 cm |
| Shipping Weight: | 85.9 kg |
