Tehnilised andmed
Output
Max Configurable Power (Watts)
1.35kWatts / 1.5kVA
Output Voltage Distortion
Less than 5 %
Output Frequency (sync to mains)
50/60 Hz +/- 3 Hz Sync to mains
Other Output Voltages
220 V, 240 V
Load Crest Factor
3 : 1
Topology
Line interactive
Waveform type
Sine wave
Transfer Time
6 ms typical : 10 ms maximum
Input
Input frequency
50/60 Hz +/- 3 Hz Auto-sensing
Input voltage range for main operations
151 - 302 Adjustable, 160 - 280V
Type of Input Protection Required
Circuit breaker
Other Input Voltages
220 V, 240 V
Batteries & Runtime
Battery type
Li-Ion (Lithium-Ion)
Typical recharge time
3hour(s)
Battery Charge Power (Watts)
100 Watts
Runtime
Efficiency
Communications & Management
Control panel
Multifunction LCD status and control console
Audible Alarm
Audible and visible alarms
Available SmartSlot™ Interface Quantity
1
Surge Protection and Filtering
Surge energy rating
645Joules
Filtering
Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
Physical
Maximum Height
131MM, 13.1CM
Maximum Width
438MM, 43.8CM
Maximum Depth
302MM, 30.2CM
Net Weight
19.5KG
Shipping weight
22.68KG
Shipping Height
279MM, 27.9CM
Shipping Width
448MM, 44.8CM
Shipping Depth
584MM, 58.4CM
Color
Black
Environmental
Operating Temperature
0 - 40 °C
Operating Relative Humidity
0 - 95 (Non-condensing) %
Operating Elevation
0 - 3048meters
Storage Temperature
-15 - 45 °C
Storage Relative Humidity
0 - 95 (Non-condensing) %
Storage Elevation
0 - 7620meters
Audible noise at 1 meter from surface of unit
45.0dBA
Online thermal dissipation
135.0BTU/hr
Protection Class
IP20
Conformance
Approvals
CE, CSA, EAC, RCM
Standard warranty
5 year repair or replace
