Tehnilised andmed
https://lanberg.eu/product/switch-lanberg-rsfe-24p-2c-360-24x-100mb-poe-2x-combo-rack-19-gigabit-ethernet-360w-v2
Number of Ethernet ports 26
Number of fiber ports 2
Number of POE ports 24
Ports specification 24x 100BASE-T 802.3af/802.3at PoE+
Maxiumum network link speed 1000 Mbps
Network Link Type Ethernet, Fiber
Management Unmanaged
Size 19"
Specialized Industrial, Rack
Type of casing Rack
Weatherproof rating IP20
Chipset Realtek - RTL8326B
PoE support Yes
PoE standards 802.3af, 802.3at
Power 370 W
PoE power supply type PoE, PoE+
Total budget for PoE 360 W
Maximum power per port 30 W
Buffer 4 Mbit
Bandwith 8.8 Gbps
MAC address table 8K
Cooling Vents, Fan
Power Requirements 100~240V AC
Surge protection 4 kV
Compatible with Jumbo Frames 9216 (B)
Packets per second 6.55 pps
IGMP snooping No
IGMP proxy No
Plug & Play Yes
Command line No
STP loop protection Not
Work signal LED
Wired standards IEEE 802.3i 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3z 1000Base-LX/SX
Functions Intelligent PoE port disconnection function, Extend mode, VLAN
Material Metal
Software No
ICT height 1 U
Length 207 mm
Width 320 mm
Height 44 mm
Weight 2.7 kg
Environment temperature 5 - 55 °C
Environment humidity 0 - 80 %
