Tehnilised andmed
Model No.
SST-RM41-H08
Chassis form factor
4U
Material
SGCC
Main metal thickness
1.2mm
Drive Support
External
- 5.25" x 3
3.5" x 5 (Hot-swappable)
Internal
- 3.5" x 4
2.5" x 2 (Support up to 15mm)
2.5" x 1 (Support up to 15mm) or slim optical drive (Support up to 12.7mm)
Cooling system
Front
- 80 x 25mm fan slot x 1
Rear
- 80 x 25mm fan slot x 2 (both fans included)
Internal
- 80mm fan x 1, 3000rpm (on hot-swap cage)
Limitation of CPU cooler
Height w/ expansion card retainer: 130mm
Height w/o expansion card retainer: 148mm
Height w/o expansion card retainer: 148mm
Expansion Slot
7 standard PCI / PCIe expansion slots
Limitation of expansion card
Length w/ 5.25” drive cage: 278mm
Length w/o 5.25” drive cage: 426mm
Length w/o 5.25” drive cage: 426mm
Power Supply
PS2 / ATX / Mini Redundant (supports up to 200mm)
2U Redundant (RM41-H08 V2.0 or after)
2U Redundant (RM41-H08 V2.0 or after)
Front I/O Port
USB 3.1 Gen1 Type-A x 2
Front buttons
Power On / Off, restart
Indicators
Power status x 1, system reset x 1, network status x 2
Dimension
430mm (W) x 176mm (H) x 446mm (D)
Net Weight 10.7 kg
