Tehnilised andmed
energy
Total performance
The total power required by the device or the total output power of the device.
750 W
Peak current
This is the maximum power required by the device or peak music power.
900 W
AC input voltage
The voltage of the AC current supplied to the product.
100 - 240 V
AC input frequency
50 - 60 Hz
Input current
10 A
Power factor correction filter (PFC)
Active
Combined current (+3.3V)
120 W
Combined current (+12V)
750 W
Combined current (-12V)
3.6 W
Combined current (+5Vsb)
15 W
Max. output current (+3.3V)
120 A
Max. output current (+12V)
62.5 A
Max output current (+5V)
22 A
Max. output current (-12V)
0.3 A
Max. output current (+5Vsb)
3 A
Energy protection properties
Features that protect the device against power problems eg overload.
Overcurrent, overload, overvoltage, short circuit
Connections and interfaces
Motherboard connector
The way in which the motherboard is connected to the power supply.
24-pin ATX
Power cable length motherboard
60 cm
Number of SATA power connectors
9
SATA power cable length
150, 500 mm
Number of Molex connectors 4pin
White 4-pinned connector used to connect a peripheral to the power supply.
4
Peripheral (Molex) power cable length
150, 500 mm
Number of PCI Express power connectors 6+2pin
4
Connections and interfaces
ATX power connector (24-pin)
Floppy drive power connection
1
Floppy drive connector
PCI Express connector
Cable type
Fully modular
Services
80 Plus certification
80 PLUS Gold
Purpose
What the product is used for.
PC
Power supply unit (PSU) form factor
ATX
Mean time between failures (MTBF)
Statistical model to indicate product/mechanism reliability, expressed in hours and percentage of duty cycle. This number (in hours) does not provide information about the mean time to failure of an individual unit/mechanism.
120,000 hours
design
Product color
The color e.g. red, blue, green, black, white.
Black
cooling
The method used to cool the device or the air around the device.
Active
Number of fans
The quantity of fans (apparatus with rotating blades that creates a current of air for cooling or ventilation).
1 fan
lighting
The device has illumination.
On/off switch
The button which is pressed to switch the device on or off.
Operating conditions
Operating temperature
The minimum and maximum temperatures at which the product can be safely operated.
0 - 50 °C
Humidity during storage
20 - 90%
Weight and dimensions
Width
The size or extent of an object from one side edge to the other.
150 mm
depth
The distance from the front to the back edge of an object.
160 mm
Height
Height of the product
86 mm
