Ouman 10” capacitive touch screen

10.1” capacitive touch screen. Cutout installation, fits to covers and doors, IP65

• Android UI

• Resolution 1366×768 (16:9)

• Can be used for browsing ounet.fi or local WEB UI

Dimensions 19,36 × 29,36 × 4,85 cm

Protection class IP65

Approvals CE

Data transferring connectors RJ45, RS232, TF/SD card, USB3.0

Power supply: 110-240 V AC, 50/60 Hz

Panel power input: 12 V DC

Power supply adapter: EU, UK or US

Interface: IP, RS232, TF/SD Card, USB 3.0, USB 3.0/OTG USB

Operating system: Android 7.1

Display: 10,1’’, 10-point capacitive screen

Aspect Ratio: 16:9

Resolution: 1366×768

Ingress Protection Rating: IP65 – for front panel

Temperature

Operating: -10°C to +60°C

Storage: -10°C to +60°C

Operation humidity: 10 to 80%

Connectors: Separable, max 2.5 mm2 (18 – 12 AWG)

Dimension: 293,6×193,6×48,5 mm (11.560×7.622×1.909 in)

Response time: 5 ms

Housing material: Aluminum alloy enclosure, color black, Bezel thickness 3 mm
