Tehnilised andmed
| General | |
| Device Type: | Switch - 8 ports - L3 Lite - smart |
| Enclosure Type: | Rack-mountable, desktop |
| Ports: | 4 x 100/1000/2.5G (PoE++) + 4 x 100/1000/2.5/5/10G (PoE++) + 2 x 10 Gigabit SFP+ (uplink) |
| Power Over Ethernet (PoE): | PoE++ |
| PoE Budget: | 295 W |
| Performance: | Fabric throughput: 140 Gbps Forwarding rate (64‑byte packets): 14.8 Mpps 2.5 Gbps copper latency (64-byte packets): 5.903 µs 2.5 Gbps copper latency (1518-byte packets): 6.040 µs 2.5 Gbps copper latency (9216-byte packets): 6.079 µs 10 Gbps copper latency (64-byte packets): 2.420 µs 10 Gbps copper latency (1518-byte packets): 2.501 µs 10 Gbps copper latency (9216-byte packets): 2.499 µs 10 Gbps fibre latency (64-byte packets): 1.257 µs 10 Gbps fibre latency (1518-byte packets): 1.337 µs 10 Gbps fibre latency (9216-byte packets): 1.348 µs |
| Capacity: | Packet buffer size: 2 MB ACL entries (ingress): 100 VLANs supported: 256 IGMP groups: 256 Priority queues: 8 DHCP snooping entries: 256 |
| MAC Address Table Size: | 32000 entries |
| Jumbo Frame Support: | 10KB |
| Routing Protocol: | IGMP, STP, RSTP, MSTP, IGMPv2, IGMPv3, MLD, MLDv2 |
| Remote Management Protocol: | IPv6, SNMP 1, SNMP 2c, SNMP 3, HTTP, HTTPS, RADIUS, RSTP, RMON 1, RMON 2, RMON 3, RMON 9, TACACS+ |
| Encryption Algorithm: | TLS 1.2 |
| Authentication Method: | RADIUS, Extensible Authentication Protocol (EAP), TACACS+ |
| Features: | ACL support, 802.1x authentication, Advanced QoS, DSCP support, DoS attack prevention, IGMP querier, IGMP snooping, egress rate limiting, EEE, cable test, GVRP, Voice VLAN, LLDP support, LLDP-MED, LACP, cloud managed, VoIP support, ZTP, DHCP snooping, protected ports, loop prevention, port mirroring, dual firmware images, firmware upgradable, store and forward, WRR, SP, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, Unknown Storm Control, flow control, full duplex mode, block unknown multicast, DHCP client, Guest VLAN, DiffServ support, loopback detection, DNS client, BPDU, EAPOL, SNTP support, UDP, Syslog support, 3 fans |
| Compliant Standards: | IEEE 802.1x, IEEE 802.1p, IEEE 802.3az, IEEE 802.1ab (LLDP), IEEE 802.3ad (LACP), IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, UPnP |
| Processor: | : 1 GHz |
| RAM: | 256 MB |
| Flash Memory: | 64 MB |
| Status Indicators: | Power, fan, link/activity/speed, PoE max |
| Expansion / Connectivity | |
| Interfaces: | 4 x 100/1000/2.5G RJ-45 PoE++ - 60 W 4 x 100/1000/2.5G/5G/10G RJ-45 PoE++ - 60 W 2 x 10GBase-X SFP+ uplink |
| Power | |
| Power Device: | Internal power supply |
| Installed Qty: | 1 |
| Power Consumption Operational: | 380 watt |
| Miscellaneous | |
| Included Accessories: | Rubber feet |
| Rack Mounting Kit: | Included |
| MTBF: | 848,553 hours |
| Localisation: | Europe |
| Dimensions & Weight | |
| Width: | 33 cm |
| Depth: | 20.6 cm |
| Height: | 4.3 cm |
| Weight: | 2.51 kg |
| Min Operating Temperature: | 0 °C |
| Max Operating Temperature: | 50 °C |
| Humidity Range Operating: | 90% (non-condensing) |
| Min Storage Temperature: | -20 °C |
| Max Storage Temperature: | 70 °C |
| Humidity Range Storage: | 95% (non-condensing) |
