| PCIe | - 1 PCIe 4.0 x8 (in x16 slot),
- 1 PCIe 4.0 x8,
- 1 PCIe 4.0 x4 (in x8 slot),
- 1 PCIe 3.0 x2 (in x4 slot)
| | M.2 | - M.2 Interface: 1 PCIe 3.0 x4
- Form Factor: 2280/22110
- Key: M-Key
|
|
| BIOS Type | | | BIOS Features | - ACPI 6.0
- SMBIOS 3.3
- Plug and Play (PnP)
- RTC (Real Time Clock) Wakeup
- UEFI 2.7
- USB Keyboard support
- PCI 3.0
|
|
| Software | | | System Management Software | - IPMI (Intelligent Platform Management Interface) v1.5 / 2.0 with KVM support
| | Power Configurations | - Power-on mode for AC power recovery, ACPI Power Management
|
|
| Hardware | - Trusted Platform Module (TPM) 2.0
|
|
| Voltage | - VBAT, System level control, Supports system management utility, Monitors CPU voltages, Chipset voltage, Chassis intrusion header, 6 -fan status, 3.3V standby, +5V standby, +5V, +3.3V, +12V, +1.8V, Memory Voltages
| | LED | - UID/remote UID LED
- BMC/IPMI Heartbeat LED
| | Temperature | - Monitoring for CPU and chassis environment
- CPU thermal trip support
- Thermal monitor 2 (TM2) support
- PECI
| | FAN | - 6x 4-pin fan headers (up to 6 fans)
- Thermal control tachometer fan connectors
- Fan speed control
- 6 fans with tachometer status monitoring
- Overheat LED indication
| | Other Features | - WOL, UID, M.2 NGFF connector, Dual Cooling Zones, CPU thermal trip support for processor protection, Control of power-on for recovery from AC power loss, Chassis intrusion detection, ACPI power management
|
|
| Operating Temperature Range | | | Non-Operating Temperature Range | | | Operating Relative Humidity Range | - 10% - 85% (non-condensing)
| | Non Operating Relative Humidity Range | - 10% - 95% (non-condensing)
|
|
