Tehnilised andmed
| General | |
| Product Type: | LED-backlit LCD flat panel display |
| Power Consumption Operational: | 493 Watt |
| Diagonal Class: | 86" |
| Commercial Use: | Yes - education / business |
| Combined With: | Touchscreen (multi touch) |
| Series: | WAF Series |
| Platform: | Android |
| Operating System: | Android OS 14 |
| TV Tuner: | No tuner |
| TV Tuner Presence: | No |
| Video Interface: | HDMI, USB-C |
| HDMI Ports Qty: | 2 ports |
| Picture Enhancements: | 72% Colour Gamut |
| Dimensions: | Without stand |
| Width: | 196.18 cm |
| Depth: | 8.77 cm |
| Height: | 117 cm |
| Weight: | 62.5 kg |
| Enclosure Colour: | Black |
| Display | |
| LCD Display Technology: | IPS |
| Resolution: | 3840 x 2160 |
| Display Format: | 4K UHD (2160p) |
| Image Aspect Ratio: | 16:9 |
| Frame Rate & Enhancement Technology: | 60 Hz Refresh Rate |
| LCD Backlight Technology: | LED backlight |
| Coating: | 25% haze |
| Dynamic Contrast Ratio: | 1200:1 |
| Brightness: | 400 cd/m² |
| Viewing Angle: | 178 degrees |
| Viewing Angle (Vertical): | 178 degrees |
| Touchpoints Qty: | 40 |
| Response Time: | 8 ms |
| Commercial Features: | Open Pluggable Standard (OPS) support |
| Operation Hours / Days: | 12 / 7 |
| Features: | Infrared multitouch technology |
| Stands & Mounts | |
| Flat Panel Mount Interface: | 800 x 600 mm |
| VESA Compatibility: | Yes |
| Media Player | |
| USB Port: | Yes |
| USB Ports Qty: | 5 |
| Configuration: | 64 GB |
| Network & Internet Multimedia | |
| Functionality: | Whiteboard, WEB browsing |
| Connectivity: | Wi-Fi, LAN, Bluetooth |
| LAN Protocol: | Ethernet |
| Wi-Fi Protocol: | 802.11ac |
| Connect & Share: | Screen Share |
| Application Store: | Google Play |
| Connections | |
| Connector Type: | HDMI input - side LAN - side 2 x USB 2.0 - side Touch - side RS-232C input - side Touch - front HDMI input - front HDMI output - side 2 x USB 3.0 - front USB - front |
| Miscellaneous | |
| Compliant Standards: | Google EDLA, EMC, FCC CFR47 Part 15 B, EN 55032:2015 + A11:2020, IEC 62368-1, UL 62368-1, IEC 60950-1, IS 13252, HDCP 2.1 |
| Power | |
| Power Device: | Power supply |
| Input Voltage: | AC 100-240 V (50/60 Hz) |
| Power Consumption Sleep: | 0.5 Watt |
| Dimensions & Weight (Shipping) | |
| Width (Shipping): | 209.5 cm |
| Depth (Shipping): | 18.5 cm |
| Height (Shipping): | 126.5 cm |
| Weight (Shipping): | 74.1 kg |
| Environmental Parameters | |
| Min Operating Temperature: | 0 °C |
| Max Operating Temperature: | 40 °C |
| Humidity Range Operating: | 10 - 80% (non-condensing) |
