IA seeria LiFePO4 aku 12V, 180Ah, Smart-BMS, Bluetooth & heating
Hind ei sisalda käibemaksu.
Toode on tellitav.
Tehnilised andmed
- Integrated heating film: Can be used even at arctic temperatures down to -35°C
- Prismatic Grade-A cells: High energy density, stable LiFePO4 technology and long lifespan
- 200A maximum continuous discharge current: Strong power reserve for inverters and on-board consumers
- Smart BMS with Bluetooth: App available in the Apple Store and on Google Play
- Compact & lightweight: 18 kg | 355 x 175 x 188 mm (DIN H8/LN5)
- Direct replacement: Replaces 12.8V 360Ah lead-acid gel AGM batteries at a significantly lower weight.
- Perfect fit: Specially adapted for under-seat installation in Fiat Ducato, Citroën and Peugeot motorhomes
| Model | 12.8V 180Ah/2304Wh |
| Replaces lead-acid gel AGM battery | 12.8V 360Ah |
| Cell type | Prismatic Grade-A cell |
| Dimensions including clamps (L x W x H) | 355 x 175 x 188 mm |
| Weight (without accessories) | 18 kg |
| menstrual cycle | >6000 @ 80% DoD |
| Internal resistance | ≤7 mΩ |
| Recommended charging voltage | 14.6V |
| Maintenance charging voltage (standby) | 13.8±0.8V |
| Recommended charging current | 54A |
| Max. charging current | 90A |
| Continuous discharge current | 200A |
| Peak discharge cutoff current | 600A (200~500ms) |
| Operating voltage range | 10 – 14.6V |
| End of the discharge voltage range | 10 – 11.2V |
| Terminal type | SAE standard |
| Protection class | IP65 |
| Charging temperature | 0~50°C |
| Discharge temperature | -20~75°C |
| Storage temperature | -5 to 35°C |
| Heating operating temperature | -35 to 5°C |
| Storage condition | Charge the battery every 3 months |
| Series and parallel availability | Maximum 4 pieces in series and 4 pieces in parallel connection |
| Certifications | CE/UL/UN38.3/MSDS/ROHS/UN 3480/CLASS 9 |
