Tehnilised andmed
Type of cabinet
Free standing
Size
19"
ICT height
42 U
Assembly type
Self-assembly
Working depth
860 mm
Front door type
Temper glass
Rear door type
Metal
Door type
Single-leaf
Maximum front door opening angle
215 °
Maximum static load
1200 kg
Slot amount for fans
6
Number of vertical rails
4
Thermostat
Yes
LCD panel
Yes
Colour
Black
RAL color
RAL9004
Weatherproof rating
IP20
Front door thickness
5 mm
Rear door thickness
1.2 mm
Upper & lower panel thickness
1.5 mm
Side panel thickness
1.2 mm
Mounting rails thickness
2 mm
Frame thickness
1.5 mm
Other elements sheet thickness
1.2 mm
Depth
1000 mm
Width
800 mm
Height
2127.5 mm
Height without casters
2020 mm
Weight
142 kg
Standard
ANSI/EIA RS-310-D, DIN 41491/PART 1, DIN 41494/PART 7, ETSI, IEC297-2:1982
Grounding Details
Back door, Frame, Front door
Included Accessories
Front lock, Legs, M6 screws, Rear lock, Side locks, Thermostat, Ventilation panel (6 fan's), Vertical cable management panel x2, Wheels with brake
