| General |
| Device Type: | UPS - rack-mountable / external |
| Height (Rack Units): | 2U |
| Power Device |
| UPS Technology: | Line interactive |
| Input Voltage: | AC 230 V |
| Input Voltage Range: | AC 166 - 278 V |
| Frequency Required: | 55 - 65 Hz |
| Input Connectors: | 1 x power IEC 60320 C14 |
| Power Output Connectors Details: | 6 x power IEC 60320 C13
1 x power IEC 60320 C19 |
| Output Voltage: | AC 200/208/220/230/240 V |
| Power Capacity: | 1980 watt / 2200 VA |
| Output Waveform: | Sinewave |
| Surge Suppression: | Yes |
| Surge Energy Rating: | 624 joules |
| Circuit Protection: | Circuit breaker |
| Efficiency: | 97% line mode |
| Power Factor (PF): | 0.9 |
| Battery |
| Quantity: | 6 |
| Technology: | Lead Acid |
| Capacity: | 9 Ah |
| Run Time (Up To): | 4.4 min at full load
8 min at 70% load
14 min at 50% load
39 min at 20% load |
| Recharge Time: | 3 hours |
| Transfer Time: | 6 ms |
| Features: | Valve-regulated, spill-proof |
| Networking |
| Remote Management Interface: | USB |
| Expansion / Connectivity |
| Interfaces: | 1 x USB |
| Expansion Slots: | 1 (total) / 1 (free) x Liebert IntelliSlot |
| Miscellaneous |
| Included Accessories: | 4-post rail rack mounting kit, tower stand |
| Cables Included: | USB cable |
| Features: | Programmable load outlets, Automatic Voltage Regulation (AVR), LCD display, emergency power off |
| Compliant Standards: | CB, EN 60020-1:2008+A1:2013, ISTA 2A, RoHS, REACH |
| Environmental Parameters |
| Min Operating Temperature: | 0 °C |
| Max Operating Temperature: | 40 °C |
| Humidity Range Operating: | 20 - 90% |
| Dimensions & Weight |
| Width: | 43.8 cm |
| Depth: | 63 cm |
| Height: | 8.8 cm |
| Weight: | 27 kg |
| Dimensions & Weight (Shipping) |
| Shipping Width: | 60 cm |
| Shipping Depth: | 76 cm |
| Shipping Height: | 24 cm |
| Shipping Weight: | 33 kg |
