Tehnilised andmed
https://www.se.com/ee/et/product/BR650MI/apc-backups-pro-650va-390w-tower-230v-6x-iec-c13-outlets-avr-lcd-user-replaceable-battery/
| Main Input Voltage | 230 V |
|---|---|
| Main Output Voltage | 230 V |
| Nimivõimsus, W | 390 W |
| Nimivõimsus, VA | 650 VA |
| Toote või komponendi tüüp | Uninterruptible power supply (UPS) |
| Input Connection Type | IEC 60320 C13 |
| output connection type | 6 IEC 60320 C13 |
| aku tüüp | Lead-acid battery |
| Käitusaeg | View Runtime Graph |
|---|---|
| Tõhusus | View Efficiency Graph |
| Battery recharge time | 12 h |
| Number of battery replacement quantity | 1 |
| aku pinge | 12 V |
| Aku mahutavus | 7,0 Ak |
| Battery charger power | 6 W rated |
| aku kasutusiga | 3…5 aasta(d) |
| Asendusaku | APCRBC110 |
| Provided equipment | kasutusjuhend USB-kaabel |
|---|
| Kõrgus | 19 cm |
|---|---|
| Width | 9,1 cm |
| Sügavus | 31 cm |
| Netokaal | 6,4 kg |
| Mounting preference | No preference |
| USB compatible | No |
| Network frequency | 50/60 Hz +/- 3 Hz auto-sensing |
|---|---|
| Input voltage limits | 176...294 V |
| Maksimaalne sisendvool | 10 A |
| Switching current capacity | 10 A |
| Maximum configurable power in W | 390 W |
|---|---|
| Output frequency | 50/60 Hz +/- 1 Hz sync to mains |
| UPS type | Line interactive |
| Wave type | Stepped approximation to a sinewave |
| Maximum configurable power in VA | 650 VA |
| Transfer time | 10 ms typical : 12 ms maximum |
| Toote sertifikaadid | A-Tick C-Tick CE EAC RCM TISI |
|---|---|
| Märgistus | GS Mark |
| Standardid | EN/IEC 62040-1:2019/A11:2021 EN/IEC 62040-2:2006/AC:2006 EN/IEC 62040-2:2018 |
| Välisõhu töötemperatuur | 0…40 °C |
|---|---|
| Suhteline niiskus | 0…95 % |
| Käitamiskõrgus | 0...10000 ft |
| Ladustamise ümbritseva õhu temperatuur | −15…45 °C |
| Storage Relative Humidity | 0…95 % |
| Säilituskõrgus | 0,0000000000…15240,0000000000 m |
| Akustiline tase | 45 dBA |
| Soojuse hajumine | 13,3 Btu/h |
| Control panel | Multifunction LCD status and control console |
|---|---|
| Alarm | Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
| Noise suppression | Full time multi-pole noise filtering : 10% of IEEE surge let-through : zero clamping response time: instantaneous |
|---|
| Pakendi tüüp 1 | PCE |
|---|---|
| Package 1 Height | 25,5 cm |
| Pakendi laius 1 | 14,3 cm |
| Pakendi pikkus 1 | 44 cm |
| Pakendi kaal 1 | 7,4 kg |
| SCC14 | 10731304346934 |
