Tehnilised andmed
https://junipersystems.filecamp.com/s/i/RGoh1eo6RbbKE52W
Depth [m]
.015
Display: width [m]
.085
Display: height [m]
.174
Height [m]
.174
Main design elements
hardware
Product Description
Rugged Handheld
Resolution: horizontal pixels
1080
Resolution: vertical pixels
2280
Touchscreen
Y
Total Weight [kg]
.32
Width [m]
.085
Year of introduction
2024
Distinguishable features
IP68, MIL-STD-810H
Main applications
Mapping, Data Collection, Communication, Data Processing
Bluetooth
Y
Ports
USB Type-C, OTG
WiFi
Y
Wireless Data Transfer
Bluetooth 5.2, WiFi 6
Compatible external GNSS receivers
Internal GPS, Optional sub-meter GNSS Expansion Pod
Compatible GNSS correction signals
SBAS, RTK
GNSS Systems Supported
Dual-band GPS, GLONASS, Beidou, Galileo, QZSS
Integrated SBAS
N
Stand alone positional accuracy [m]
0
Audio: speaker
Y
Audio: microphone
Y
Built-in Camera: megapixels
48
Hard Disk [MB]
128000
Hard Disk
Solid State
Operating System
Android 14 up to Android 18
Processor
Qualcomm QCM4490 Octa-Core
RAM [MB]
8000
Types of Replaceable Memory
MicroSDXC Card Storage up to 512 GB
Operating temperature: max. [°C]
60
Operating temperature: min. [°C]
-120
Water and dust proof [IP]
IP68
Humidity resistance
507.6
Shock proof
MIL-STD-810H
Operation time per battery [hr]
9
Battery Field Replaceable
Y
Pole mount available
Y
