  3. Eaton 5SC 500VA/300W line-interactive UPS, tower, 4 outlets IEC-C13 10A, C14 input, shutdown software

Eaton 5SC 500VA/300W line-interactive UPS, tower, 4 outlets IEC-C13 10A, C14 input, shutdown software

132.50 € 132.5 EUR

185.00 €

Lisa ostukorvi

Hind ei sisalda käibemaksu.
Toode on tellitav.

Tehnilised andmed

PRODUCT NAME
Eaton 5SC UPS
CATALOG NUMBER
5SC500I
PRODUCT LENGTH/DEPTH
150 mm
PRODUCT HEIGHT
210 mm
PRODUCT WIDTH
240 mm
PRODUCT WEIGHT
6.6 kg
WARRANTY
2 year
COMPLIANCES
CE Marked
TUV
CERTIFICATIONS
IEC/EN 62040-1
UL 1778
IEC/EN 62040-2
CE
EAC
cTUVus
UPC
743172045140

PRODUCT SPECIFICATIONS

SECONDARY FREQUENCY - MAX
60 Hz
OUTPUT WAVEFORM
Sine wave
WATTAGE
350 W
OUTPUT POWER FACTOR
0.7
FORM FACTOR
Tower
ENCLOSURE
Black
INCLUDES NETWORK CARD
No
INPUT CONNECTION
C14
INPUT VOLTAGE - MIN
184 V
OUTPUT VOLTAGE - MAX
240 V
SECONDARY FREQUENCY - MIN
50 Hz
SOFTWARE COMPATIBILITY
Eaton Intelligent Power Protector
BATTERY REPLACEMENT
User replaceable
BATTERY TYPE
Lead-acid maintenance-free (replaceable)
EFFICIENCY
95
SPECIAL FEATURES
  • Automatic Voltage Regulation (AVR)
  • Delivers clean sinewave output
  • LCD display for real-time status and measurements
  • Reliable and affordable UPS for tower servers, networking and storage
  • Saves space with a compact tower design
  • Fully integrates with Eaton Intelligent Power Manager software
  • 1 USB port + 1 serial port
  • 1 USB port + 1 serial port
  • Advanced Battery Management (ABM) technology to increase battery lifetime
CONSTRUCTION TYPE
Free standing model
OUTPUT VOLTAGE - MIN
220 V
COLOR
Black
EXTENDED BATTERY CAPABILITY
No
OUTPUT VOLTAGE RANGE
230 V (+6%/-10%)
TOPOLOGY
Line-interactive
BTU RATING
Online: 72
RUNTIME AT HALF LOAD
13 min
INPUT NOMINAL VOLTAGE
230V default (220/230/240V)
INPUT FREQUENCY RANGE
45-55 Hz (50 Hz system), 55-65 Hz (60 Hz system)
INPUT VOLTAGE - MAX
276 V
VOLTAGE TYPE
AC
PHASE (OUTPUT)
1
BATTERY MANAGEMENT
ABM or constant voltage charging method (user selectable), automatic battery test, deep discharge protection
AUTO SHUTDOWN FUNCTION
Yes
NUMBER OF OUTPUTS C13
4
VA RATING
500 VA
POTENTIAL FREE SWITCH CONTACT
No
RECEPTACLE
(4) C13
PHASE (INPUT)
1
PACKAGE CONTENTS
  • USB cable
  • Serial cable
  • (2) IEC-IEC cables
  • Quickstart guide
  • Safety instructions
NOISE LEVEL
<25 dB at 1 meter
FEED TYPE
1
RUNTIME GRAPH
View runtime graph
USER INTERFACE
LCD Display
BATTERY QUANTITY
1
VOLTAGE
230V
TEMPERATURE RANGE
0-90% non-condensing
ETHERNET INTERFACE
No
COMMUNICATION
  • USB port (HID compliant)
  • Serial port (RS232)
RELATIVE HUMIDITY
0-90% non-condensing
RACK MOUNTING KIT
No
OUTPUT FREQUENCY
50/60 Hz
RUNTIME AT FULL LOAD
5 min
TYPE OF INTERFACE
Other
PRIMARY FREQUENCY - MIN
45 Hz
BATTERY RATING
12 V / 9 Ah
TYPE
UPS
OUTPUT NOMINAL VOLTAGE
230V default (220/230/240V)
EXPANSION SLOTS
No
INPUT VOLTAGE RANGE
184-276 V
NOMINAL FREQUENCY
50-60 Hz
PRIMARY FREQUENCY - MAX
65 Hz
ALTITUDE
2000 m
