| 1 | Depth / Length of the package [mm] | 185 |
| 2 | Package width [mm] | 132 |
| 3 | Package height [mm] | 55 |
| 4 | Dimensions (D/L x W x H) | 177 x 125 x 48 mm |
| 5 | Color | Gray, green |
| 6 | Degree of protection | IP30 |
| 7 | Net weight [kg] | 0.554 |
| 8 | Guarantee | 24 months |
| 9 | Nominal voltage | 12/24V |
| 10 | Certificate | CE |
| 11 | Maximum voltage | (PV) 60V |
| 12 | Material | ABS, metal |
| 13 | Display | LCD |
| 14 | Rated current | 20A |
| 15 | Operating temperature | -20˚C ~ +55˚C |
| 16 | Packaging | Box |
| 17 | MPPT efficiency | 95% |
| 18 | Included in the set | 1 x MPPT Controller 1 x User Manual |
| 19 | Additional information | Equipped with a temperature sensor Bluetooth USB communication: 5V/2A |
| 20 | Security | Short circuit protection Against overheating Against overload Against overcharging |
| 21 | Application | Home photovoltaic systems Portable solar kits Solar systems in campers and caravans Solar installations on boats and yachts Any location requiring efficient and reliable battery charging management |
| 22 | Storage temperature | -30˚C to +80˚C |
| 23 | Gross weight [kg] | 0.623 |
| 24 | Producer | Qoltec |
| 25 | Maximum power | 260W for 12V PV 520W for 24V PV |
