Tehnilised andmed
Type
VRLA
Technology
AGM
Rated capacity
20Ah
Voltage
12V
Maximum charging current
6A
Max. Discharge Current
300A (5 sec)
Float charge
13.6 - 13.8 V
Cyclic charge
14.5 - 15.0 V
Connector
T3 (M5)
Internal resistance
12mΩ
Capacity affected by temperature (10HR)
40°C : 102%
25°C : 100%
0°C : 85%
-15°C : 65%
25°C : 100%
0°C : 85%
-15°C : 65%
Self-discharge (25℃)
Maximum reliability and very low self-discharge.
After 3 months of storage, it retains: 91%.
After 6 months of storage, it retains: 82%.
After 12 months of storage, it retains: 65%.
After 3 months of storage, it retains: 91%.
After 6 months of storage, it retains: 82%.
After 12 months of storage, it retains: 65%.
Service life
10 years (when working with an uninterruptible power supply UPS)
Usage
- Alarm systems and monitoring
- UPS
- Electronic toys
- Motorcycles, quads, scooters, etc.
- Forklifts, golf carts, wheelchairs
- Solar battery systems
- Medical equipment
- Emergency lighting
- UPS
- Electronic toys
- Motorcycles, quads, scooters, etc.
- Forklifts, golf carts, wheelchairs
- Solar battery systems
- Medical equipment
- Emergency lighting
Additional information
- wide operating temperature range,
- resistance to low temperatures,
- maintenance-free
- resistance to low temperatures,
- maintenance-free
Other parameters
Colour
Grey
Temperature range
Discharge: -15˚C ~ +50˚C
Charge: -10˚C ~ +50˚C
Storage: -20˚C ~ +50˚C
Charge: -10˚C ~ +50˚C
Storage: -20˚C ~ +50˚C
Dimensions deviation
+/- 2%
Dimensions (D/L x W x H)
72 x 182 x 165 mm
Package contents
AGM battery 20Ah
Package depth / length [mm]
190
Package width [mm]
90
Package height [mm]
170
Weight deviation
+/- 10%
Net weight [kg]
5.5000
Gross weight [kg]
5.5200
