Tehnilised andmed
https://psref.lenovo.com/Detail/ThinkStation_P2_Tower?M=30FR004SGE
| PERFORMANCE | |
| Processor | Intel® Core™ i5-14500, 14C (6P + 8E) / 20T, P-core 2.6 / 5.0GHz, E-core 1.9 / 3.7GHz, 24MB |
| Processor Sockets | 1x FCLGA1700 |
| Integrated Graphics | Integrated Intel® UHD Graphics 770 |
| Discrete Graphics | None |
| Chipset | Intel® W680 Chipset |
| Memory | 1x 16GB UDIMM DDR5-4400 Non-ECC |
| Memory Slots | Four DDR5 UDIMM slots, dual-channel capable |
| Max Memory | Up to 128GB (4x 32GB DDR5 UDIMM) |
| PCIe NVMe Controller | Integrated NVMe® Controller |
| PCIe NVMe Drive | 1x 512GB SSD M.2 2280 PCIe® 4.0x4 Performance NVMe® Opal |
| SATA Controller | Onboard Intel® RSTe SATA RAID |
| SATA/SAS Drive | None |
| Storage Support | Up to 2x 3.5" SATA HDD; also supports up to 3x M.2 SSD (two by onboard, one by M.2 to PCIe® adapter)
• 3.5" HDD up to 4TB each
• Onboard M.2 SSD up to 4TB each
• M.2 SSD by M.2 to PCIe adapter up to 2TB |
| Audio Chip | High Definition (HD) Audio, Realtek® ALC897Q-CG codec |
| Power Supply | 500W Platinum Fixed |
| DESIGN | |
| Keyboard | USB Calliope Keyboard, Black, German |
| Mouse | USB Calliope Mouse, Black |
| Expansion Slots | Supports four PCIe® slots with two PCIe 4.0 x16 and two PCIe 3.0 x1.
• Slot 1: PCIe 4.0 x16, full height, full length, 75W, double-width
• Slot 2: PCIe 3.0 x1, full height, half length, 25W
• Slot 3: PCIe 4.0 x16 (x4 lanes), full height, half length, 25W
• Slot 4: PCIe 3.0 x1, full height, half length, 25W |
| Bays | Three internal disk bays, up to two 3.5" bays plus one 2.5" bay:
• Bay 1 supports one 3.5" HDD, standard; or one 2.5" HDD / SSD, optional
• Bay 2 supports one 3.5" HDD or 2.5" HDD / SSD, optional
• Bay 3 supports one 2.5" HDD / SSD, optional
• Front Access HDD Bay supports one 3.5" HDD or 2.5" HDD / SSD, optional, occupies Bay 2 location |
| Dimensions (WxDxH) | 170 x 315.35 x 376 mm (6.7 x 12.4 x 14.8 inches, with feet) |
| Weight | 9.67 kg (21.32 lbs, maximum configuration) |
| CONNECTIVITY | |
| Onboard Ethernet | Intel® I219-LM, 1x GbE RJ-45 |
| Card Reader | SD Card Reader |
| Front Ports |
|
| Rear Ports |
|
| Optional Rear Ports (configured) | None |
| SECURITY & PRIVACY | |
| Security Chip | Discrete TPM 2.0, TCG certified, FIPS 140-2 certified |
| Physical Locks |
|
| Cover Lock | None |
| Cable Lock | No Cable |
| Chassis Intrusion Switch | None |
| MANAGEABILITY | |
| System Management | Intel® vPro® Enterprise with Intel AMT 16 |
| CERTIFICATIONS | |
| Green Certifications |
|
| ISV Certifications | Please visit ISV certifications for Lenovo® Workstations |
| SOFTWARE | |
| Operating System | Windows® 11 Pro, German |
